Multihog CX
One machine, one driver, endless applications.
Overview
The CX is a light, narrow and short chassis model that combines a compact build with a powerful and ultra-fuel efficient engine and greater carrying capacity as well as pivot steer, four-wheel drive with spring suspension and robust ROPS tested cab.
-
Width
1200 – 1610mm
-
Height
2155 – 2244mm
-
Length
3860 mm
-
Unladen Weight
2200 – 2500kg
-
Engine
75HP Deutz, Diesel (Tier IV Final)
-
Gross Weight
3500 – 4000kg
-
Max Hydraulic Flow
120 litres per minute
-
PTO
Load-sensing hydraulics front and rear with optional front mechanical PTO
-
Drive
Patented ‘sure drive’ 4-wheel drive (2 stage differential lock)
-
Operating License
Standard UK DVLA Driving License
-
Road Registered Speed
40 kph
-
Operating Pressure
220 bar
-
INCREASED COMFORT
Cabin size has increased by 46% making it a much more comfortable working environment, and the entry redesigned to make access easier for operators.
-
IMPROVED DRIVE SYSTEM
The new ‘push and go’ system allows for simple operation with just an accelerator and brake. The cruise control has been adapted to simply operate at the push of a button.
-
Efficient servicing
Integrated on-board diagnostics and new easily accessible side panels for servicing all components.
-
Operational improvements
The model features pre-set operating modes for tasks such as snow clearance and grass cutting, reducing downtime, and maximising efficiencies.
-
SNOW PLOUGH
1.3 – 1.5m width
-
DE-ICER
975 litre capacity
-
Salt Spreader
0.8m³ capacity
-
SNOW BLOWER
1.2 – 1.5m width
-
SNOW BRUSH
1.2 – 1.8m width
-
FLAIL ARM
3.5m reach | 1m width cutting head
-
FLAIL MOWER
1.2 – 2m width
-
ROTARY MOWER
1.5 – 3.5m width
-
CYLINDER MOWER
2.1 – 3.3m width
-
HIGH PRESSURE WASHER
220 bar | 1850mm wide spray bar
-
WEED BRUSH
90cm brush diameter
-
SOLAR PANEL CLEANER
3 – 5m reach
REDEFINING WHAT’S POSSIBLE
Versatile range of applications
Despite its small size at just 1200mm wide, the CX is a great tool for maintaining hard to access areas such as car parks, cycleways, and town centres.
Weed Control
Winter Maintenance
Grounds Maintenance
Refuse & Street Cleaning
COMPact anD POWERFUL
Light, narrow and chassis model that combines a compact build with a powerful and ultra-fuel efficient 75HP engine and a powerful hydraulic output of up to 100 litres per minute.
VERSATILE
The CX accepts hydraulic and mechanically driven PTO attachments by way of a three-point linkage to the front and rear, enabling users to mount existing tractor attachments.
CLEAN EMISSIONS
75 hp Deutz engine, meeting Stage V/Tier 4 final emissions regulations without requiring Ad Blue.
REDEFINING WHAT’S POSSIBLE
Up for any challenge
Despite its small size at just 1200mm wide, the CX is a great tool for maintaining hard to access areas such as car parks, cycleways, and town centres.
- Snow Clearance
- Weed Removal
- Vegetation Management
SETTING THE STANDARD
New and improved
The newly upgraded model is better than ever before, with various upgrades completed with the operator and performance in mind.
- The cabin is 46% larger, which makes it a more comfortable working environment.
- New ‘push to go’ drive system.
- The new control panel means all double-acting hydraulic functions are at your fingertips.
Take a closer look
COMPACT YET POWERFUL
The Multihog CX is a great all-rounder for maintaining cycleways and narrow access areas.
COMPARE MODELS
Explore the Multihog range
The Multihog model range ranges from small all-rounders to high-performance all-rounders.
Multihog CX
Multihog CX
The compact design makes the CX the ideal solution for maintaining hard to reach areas.
- cycleway maintenance
- PARKS AND GREEN SPACES
- TOWN CENTRES
-
POWER
75HP
-
GROSS VEHICLE WEIGHT
3500KG
-
MAX HYDRAULIC FLOW
100 litres per minute
-
PTO
Load-sensing hydraulics front and rear, with optional mechanical PTO
-
Multihog MX
Multihog MX
The machine’s power and rear carrying capacity makes it the ideal unit for heavy duty tasks such as winter maintenance and patching.
- DE-ICING
- GRITTING
- GRASS CUTTING
-
POWER
130HP
-
GROSS VEHICLE WEIGHT
7000KG
-
MAX HYDRAULIC FLOW
120 litres per minute
-
PTO
Load-sensing PTO hydraulics front & rear
Multihog MH
Multihog MH
This proven solution and award-winning machine is the most popular Multihog model in the UK used by over a third of all local authorities and most major airports.
- PRODUCTIVE PATCHING
- VERGE MAINTENANCE
- SNOW CLEARANCE
-
POWER
75HP
-
GROSS VEHICLE WEIGHT
6000KG
-
MAX HYDRAULIC FLOW
120 litres per minute
-
PTO
Load-sensing hydraulics front and rear
Compact Sweeper
Compact Sweeper
A multi-purpose compact sweeper designed to outlast and outperform similar sized sweepers, boasting outstanding suction performance, operational efficiency and unmatched versatility.
- DEDICATED SWEEPER
- STREET CLEANSING
- CYCLE-WAY MAINTENANCE
-
POWER
75HP
-
GROSS VEHICLE WEIGHT
3500KG
-
HOPPER VOLUME
1.5M³
-
EMISSION CLASS
Stage V
Attachments
The versatile CX accepts hydraulic and mechanically driven PTO attachments by way of a three-point linkage to the front and rear.
